Precision Ultra Small Ball Bearing Technical Parameter
Bearing No		Dimensions(mm)				(KN) BasicRatedload		(r/min) Limitsd Speed		(g)
Bearing No	Bearing No	d	D	B		Cr	Cor	Oil	Grease	Mass
Bearing No	Bearing No	d	D	Open-ended	Hermetic type	Cr	Cor	Oil	Grease	Mass
68/1.5	68/1.5 ZZ	1.5	4	1.2	2	125	37	124000	105000	0.07
69/1.5	69/1.5 ZZ	1.5	5	2	2.6	186	57	111000	94000	0.18
60/1.5	60/1.5 ZZ	1.5	6	2.5	3	330	99	101000	86000	0.32
MR42	MR42 ZZ	2	4	1.2	2	113	35	116000	98000	0.05
682	682 ZZ	2	5	1.5	2.3	188	59	111000	94000	0.13
MR52	MR52 ZZ	2	5	2	2.5	188	59	111000	94000	0.17
692	692 ZZ	2	6	2.3	3	331	100	101000	86000	0.28
MR62	MR62 ZZ	2	6	2.5	2.5	331	100	101000	86000	0.30
MR72	MR72 ZZ	2	7	2.5	3	380	126	90000	76000	0.46
602	602 ZZ	2	7	2.8	3.5	380	126	90000	76000	0.50
MR5/2.5	MR5/2.5 ZZ	2.5	5	1.5	2.3	188	59	82000	70000	0.21
68/2.5	68/2.5 ZZ	2.5	6	1.8	2.6	206	75	96000	81000	0.22
69/2.5	69/2.5 ZZ	2.5	7	2.5	3.5	380	126	90000	76000	0.42
MR8/2.5	MR8/2.5 ZZ	2.5	8	2.5	2.8	559	179	82000	70000	0.52
60/2.5	60/2.5 ZZ	2.5	8	2.8	4	551	175	85000	72000	0.63
MR63	MR63 ZZ	3	6	2	2.5	206	75	80000	71000	0.22
683	683 ZZ	3	7	2	3	380	126	75000	63000	0.32
MR83	MR83 ZZ	3	8	2.5	3	380	126	67000	60000	0.51
693	693 ZZ	3	8	3	4	552	177	67000	60000	0.60
MR93	MR93 ZZ	3	9	2.5	4	634	219	67000	56000	0.75
603	603 ZZ	3	9	3	5	634	219	67000	56000	0.80
623	623 ZZ	3	10	4	4	641	226	60000	50000	1.45
MR74	MR74 ZZ	4	7	2	2.5	251	106	67000	60000	0.23
MR84	MR84 ZZ	4	8	2	3	392	139	67000	56000	0.39
684	684 ZZ	4	9	2.5	4	644	226	63000	53000	0.65
MR104	MR104 ZZ	4	10	3	4	714	265	60000	50000	0.96
694	694 ZZ	4	11	4	4	714	265	56000	48000	1.60
604	604 ZZ	4	12	4	4	958	347	54000	46000	2.10
624	624 ZZ	4	13	5	5	1310	488	48000	40000	3.10
634	634 ZZ	4	16	5	5	1730	670	43000	36000	5.30
MR85	MR85 ZZ	5	8	2	2.5	276	131	63000	53000	0.25
MR95	MR95 ZZ	5	9	2.5	3	493	206	60000	50000	0.54
MR105	MR105 ZZ	5	10	3	4	714	265	60000	50000	0.91
MR115	MR115 ZZ	5	11	4	4	714	265	56000	48000	1.05
685	685 ZZ	5	11	3	5	714	265	53000	45000	1.16
695	695 ZZ	5	13	4	4	1074	423	50000	43000	2.40
605	605 ZZ	5	14	5	5	1330	505	50000	40000	3.00
625	625 ZZ	5	16	5	5	1730	670	43000	36000	4.50
635	635 ZZ	5	19	6	6	2340	885	40000	32000	8.50
MR106	MR106 ZZ	6	10	2.5	3	457	193	53000	45000	0.55
MR126	MR126 ZZ	6	12	3	4	832	363	56000	48000	1.25
686	686 ZZ	6	13	3.5	5	1080	440	50000	40000	1.87
696	696 ZZ	6	15	5	5	1730	670	45000	40000	3.90
606	606 ZZ	6	17	6	6	2260	835	45000	38000	5.50
626	626 ZZ	6	19	6	6	2340	885	40000	32000	7.80
MR117	MR117 ZZ	7	11	2.5	3	448	193	50000	43000	0.59
MR137	MR137 ZZ	7	13	3	4	880	409	48000	40000	1.52
687	687 ZZ	7	14	3.5	5	1170	510	45000	40000	2.00
697	697 ZZ	7	17	5	5	1610	715	43000	36000	4.80
MR128	MR128 ZZ	8	12	2.5	3.5	506	246	48000	40000	0.70
MR148	MR148 ZZ	8	14	3.5	4	820	385	45000	38000	1.90
688	688 ZZ	8	16	4	5	1610	711	43000	36000	3.00
