Outside Dia 19 to 170mm Self-aligning Ball Bearing Bore Size 5 to 80mm Dynamic Load 8710 Engineered for Smooth Operation

Product Description:

The Self-aligning Ball Bearing, model 22322, is a highly reliable and versatile component designed to meet the demanding requirements of various industrial applications. With a bore size ranging from 5 to 80mm, this bearing is engineered to accommodate a wide array of shaft diameters, providing flexibility and precision in mechanical assemblies. The outside diameter varies between 19 and 170mm, allowing the bearing to fit seamlessly into different machinery and equipment configurations.

This self-aligning spherical ball bearing is distinguished by its unique design, which includes a steel holder that enhances durability and stability during operation. The steel holder not only provides robust support but also contributes to the bearing’s ability to maintain alignment under fluctuating load conditions. This feature is particularly beneficial in applications where shaft deflection or misalignment is common, as it helps to reduce wear and extend the service life of the bearing.

One of the key attributes of the Self-aligning Roller Bearing is its thickness of 12mm, which strikes an optimal balance between strength and compactness. This thickness ensures that the bearing can withstand substantial radial and axial loads without compromising on size or weight. The compact design also facilitates easy integration into tight spaces, making it ideal for complex machinery where space constraints are a concern.

The self-aligning spherical ball bearing design incorporates two rows of balls and a common sphered raceway in the outer ring. This configuration allows the bearing to compensate for angular misalignment caused by shaft flexure or mounting errors. As a result, it minimizes friction and heat generation, contributing to smoother operation and increased efficiency. The self-aligning feature is especially advantageous in applications such as electric motors, conveyors, and agricultural machinery, where alignment deviations can occur frequently.

Durability and performance are further enhanced by the high-quality materials used in the construction of the 22322 model. The steel holder is manufactured from premium-grade steel, ensuring resistance to corrosion and mechanical stress. This robust construction allows the bearing to perform reliably in harsh environments, including those with high temperatures, dust, or moisture.

Maintenance is simplified with the Self-aligning Roller Bearing due to its ability to accommodate misalignment without requiring frequent adjustments or replacements. This reduces downtime and maintenance costs, making it a cost-effective choice for long-term operations. Furthermore, the bearing’s smooth operation reduces noise and vibration, contributing to a quieter and more stable working environment.

In summary, the Self-aligning Spherical Ball Bearing model 22322 offers a combination of precision engineering, durability, and versatility. Its bore size range of 5 to 80mm, outside diameter range of 19 to 170mm, and a thickness of 12mm, coupled with a robust steel holder, make it an ideal solution for applications requiring reliable self-alignment and high load capacity. Whether used in industrial machinery, automotive systems, or agricultural equipment, this bearing delivers exceptional performance and longevity, ensuring optimal functionality and efficiency in various operational contexts.

Features:

• Product Name: Self-aligning Ball Bearing
• Type: Self-aligning Spherical Ball Bearing
• Thickness: 12 mm
• Dynamic Load Capacity: 8710 N
• External Diameter: 32 mm
• Internal Diameter: 75 mm
• Features self-aligning capability to accommodate shaft misalignment
• Suitable for applications requiring Self-aligning Roller Bearing performance
• High durability and reliability in various operating conditions

Technical Parameters:

Applications:

The Self-aligning Ball Bearing is a specialized type of bearing designed to accommodate misalignment between the shaft and the housing. This self-adjusting ball bearing features an internal diameter of 75 mm and an external diameter of 32 mm, making it suitable for a variety of mechanical applications where precision and durability are essential. The width of these bearings varies, commonly ranging from 7mm to 40mm, allowing for flexibility in fitting different equipment requirements. Additionally, the cage material options include pressed steel, brass, and polyamide, each offering distinct advantages in terms of strength, corrosion resistance, and noise reduction.

Self-aligning ball bearings are widely used in industrial machinery where shaft deflections and mounting errors are common. Their unique design enables them to adjust automatically to misalignments, preventing premature wear and ensuring smooth operation. This makes them ideal for use in conveyors, agricultural machinery, and textile machinery where operational conditions can be unpredictable and alignment may shift during use.

In automotive applications, self-aligning ball bearings play a critical role in wheel hubs and transmissions where they help absorb radial and axial loads while compensating for misalignment between components. The choice of cage material – whether pressed steel for heavy-duty applications, brass for enhanced durability, or polyamide for quieter operation – allows manufacturers to customize the bearing to specific performance needs.

Furthermore, these self-aligning ball bearings are also suitable for electric motors, pumps, and fans, where maintaining alignment is crucial for reducing vibration and noise. Their ability to self-correct alignment issues helps extend the lifespan of machinery and reduce maintenance downtime, making them an excellent choice for continuous operation environments.

Overall, the versatility of the self-adjusting ball bearing, combined with its robust internal diameter of 75 mm and external diameter of 32 mm, and the availability of various cage materials and widths, makes it an indispensable component across numerous industries. Whether in heavy industrial equipment or precision instruments, self-aligning ball bearings ensure reliable performance and operational efficiency under diverse application scenarios.

Customization:

Our Self-aligning Ball Bearing products can be customized to meet your specific requirements. With an outside diameter ranging from 19mm to 170mm and an external diameter of 32mm, we ensure precision and reliability in every unit. The width of our Self-adjusting Ball Bearing varies, commonly between 7mm to 40mm, allowing flexibility for different applications. Additionally, the thickness is maintained at 12mm to provide optimal performance. Whether you need a Self-adjusting Ball Bearing or a Self-aligning Spherical Ball Bearing, our customization services guarantee high quality and tailored solutions to fit your needs.

Support and Services:

Our Self-aligning Ball Bearings are designed to accommodate misalignment between the shaft and housing, ensuring smooth operation and extended service life. For optimal performance, it is essential to follow proper installation, lubrication, and maintenance procedures.

Installation:

Ensure that the bearing is aligned correctly and mounted without applying excessive force that could damage the bearing components. Use appropriate tools and techniques to press the bearing onto the shaft and into the housing.

Lubrication:

Proper lubrication is critical for the longevity of Self-aligning Ball Bearings. Use the recommended type and amount of lubricant specified in the product manual. Regularly check and replenish lubricant levels to prevent contamination and wear.

Maintenance:

Regular inspection of the bearing is advised to detect early signs of wear or damage. Monitor operating temperature, vibration, and noise levels to identify potential issues. Replace bearings promptly if any abnormalities are detected to avoid equipment failure.

Technical Support:

For detailed technical assistance, including bearing selection, installation guidance, and troubleshooting, consult the product documentation or contact our technical support team. We provide comprehensive support to ensure your Self-aligning Ball Bearings perform reliably in your application.

Packing and Shipping:

Our Self-aligning Ball Bearings are carefully packaged to ensure maximum protection during transit. Each bearing is individually wrapped in protective material to prevent corrosion and physical damage. The bearings are then placed in sturdy, custom-designed boxes that provide cushioning and support.

For bulk orders, the individual boxes are securely packed into larger cartons with additional padding to minimize movement and impact. All packages are clearly labeled with product details and handling instructions to ensure proper care throughout the shipping process.

We partner with reliable logistics providers to guarantee timely and safe delivery to your destination. Whether shipped domestically or internationally, our packaging and shipping methods comply with industry standards to maintain the integrity and performance of the Self-aligning Ball Bearings upon arrival.

FAQ:

Q1: What is a self-aligning ball bearing?

A1: A self-aligning ball bearing is a type of bearing that can accommodate misalignment between the shaft and the housing. It features two rows of balls and a common spherical raceway in the outer ring, allowing it to self-align during operation.

Q2: What are the typical applications of self-aligning ball bearings?

A2: Self-aligning ball bearings are commonly used in applications where shaft deflection or misalignment is expected, such as in agricultural machinery, conveyors, electric motors, and fans.

Q3: What materials are self-aligning ball bearings made from?

A3: These bearings are typically made from high-quality chrome steel for the rings and balls, with cages made from steel, brass, or polymer depending on the specific application requirements.

Q4: What are the key advantages of using self-aligning ball bearings?

A4: The main advantages include their ability to tolerate angular misalignment, reduce friction, operate smoothly at high speeds, and provide longer service life under varying load conditions.

Q5: How do I maintain self-aligning ball bearings for optimal performance?

A5: Regular maintenance includes proper lubrication with the recommended grease or oil, periodic inspection for wear or damage, and ensuring correct installation to avoid excessive loads or misalignment beyond the bearing's capabilities.
