Steel Holder Self-aligning Bearing Unit Incorporating Brass Cage Material Designed for Operation and Extended Bearing Life

Product Description:

The Self-aligning Ball Bearing is a highly versatile and reliable component designed to accommodate misalignment in rotating shafts, ensuring smooth and efficient operation in various mechanical systems. Known for its superior performance and durability, this bearing type is essential in applications where shaft deflection or mounting errors may occur. The product is engineered to meet the demands of modern machinery, providing excellent functionality and longevity.

This Self-aligning Ball Bearing features a bore size range from 5mm to 80mm, making it suitable for a wide array of industrial applications. Whether you require a compact bearing for small machinery or a larger unit for heavy-duty equipment, this product offers flexibility to meet your specific needs. The bore size range ensures compatibility with various shaft diameters, enhancing its adaptability across different sectors.

One of the key characteristics of this bearing is its thickness, which is set at 12mm. This consistent thickness contributes to the bearing’s robustness and ability to withstand axial and radial loads effectively. The 12mm thickness strikes an optimal balance between strength and compactness, allowing the bearing to fit into tight spaces without compromising performance.

The holder of the Self-aligning Ball Bearing is constructed from high-quality steel, providing exceptional strength and resistance to wear and corrosion. The steel holder ensures the bearing maintains its structural integrity under demanding conditions, such as high speeds, heavy loads, and exposure to harsh environments. This durable construction extends the service life of the bearing, reducing maintenance requirements and downtime.

The width of the bearing varies, commonly ranging from 7mm to 40mm. This variability in width allows for customization based on the specific application requirements. A narrower width may be preferred in compact designs where space is limited, while a wider bearing can support higher loads and provide additional stability. This range of widths enhances the versatility of the Self-aligning Ball Bearing, making it suitable for diverse mechanical configurations.

As a Self-aligning Spherical Ball Bearing, this product excels in automatically compensating for shaft misalignment. The spherical design of the outer ring allows the bearing to adjust to angular misalignments without causing undue stress or wear on the components. This self-adjusting capability reduces the risk of premature bearing failure and improves the overall reliability of the machinery.

In addition to being a Self-aligning Ball Bearing, it is also recognized as a Self-adjusting Ball Bearing due to its inherent ability to maintain alignment under varying operating conditions. This feature is particularly valuable in applications where precise alignment is difficult to achieve or maintain, such as in agricultural machinery, conveyors, and heavy equipment. By accommodating misalignment, the bearing minimizes friction and heat generation, contributing to energy efficiency and longer equipment life.

Moreover, the Self-aligning Ball Bearing shares characteristics with Self-aligning Roller Bearings, offering similar benefits in terms of alignment correction and load distribution. However, the ball bearing design typically provides lower friction and smoother operation compared to roller bearings, making it ideal for high-speed applications requiring minimal noise and vibration.

In summary, the Self-aligning Ball Bearing is a robust, adaptable, and efficient solution for managing shaft misalignment in a wide range of mechanical systems. Its broad bore size range of 5mm to 80mm, consistent 12mm thickness, durable steel holder, and variable width options from 7mm to 40mm make it an excellent choice for many industrial uses. The bearing’s self-aligning spherical ball bearing design ensures reliable performance, reduced maintenance, and enhanced operational lifespan, making it an indispensable component in modern machinery.

Features:

• Product Name: Self-aligning Ball Bearing
• Model: 22322
• Vibration Levels: Z1V1, Z2V2, Z3V3
• Width: Varies, commonly from 7mm to 40mm
• Internal Diameter: 75mm
• Designed as a Self-aligning Roller Bearing for enhanced alignment capabilities
• Suitable for use in Self-aligning Bearing Unit applications
• Reliable performance in various mechanical systems requiring Self-aligning Bearing Unit components

Technical Parameters:

Applications:

The Self-aligning Ball Bearing, specifically the model 22322 with an external diameter of 32mm and an internal diameter of 75mm, is designed to excel in a wide range of industrial and mechanical applications. Its unique self-aligning capability allows it to accommodate misalignment of up to 3 degrees, making it an ideal solution in scenarios where shaft deflections or mounting inaccuracies are common. This feature ensures smooth operation and reduces the risk of premature bearing failure, enhancing the reliability and longevity of machinery.

The Self-aligning Spherical Ball Bearing is particularly well-suited for use in heavy-duty equipment that operates under variable loads and misalignment conditions. Industries such as mining, construction, and agriculture frequently employ these bearings in their conveyor systems, heavy machinery, and agricultural implements. The bearing’s ability to maintain performance despite angular misalignment makes it a preferred choice for applications involving uneven or flexible shafts.

In addition to industrial machinery, the Self-aligning Bearing Unit finds extensive use in electric motors, pumps, and fans, where vibration levels can vary significantly. This model supports vibration specifications ranging from Z1V1 to Z3V3, ensuring stable operation under different vibration intensities. Its resilience to vibration contributes to smoother operation and decreases maintenance requirements.

The compact external diameter of 32mm combined with the robust internal diameter of 75mm allows the Self-aligning Ball Bearing model 22322 to fit into a variety of equipment designs, providing engineers with flexibility in mechanical design. This makes it suitable for both new installations and retrofitting existing systems where alignment issues have been problematic.

Moreover, the Self-aligning Bearing Unit is a preferred component in applications requiring easy installation and maintenance. The self-aligning feature reduces the need for precise shaft alignment, saving time during assembly and minimizing downtime during maintenance. This advantage is particularly beneficial in automated production lines and other high-throughput industrial environments.

In summary, the Self-aligning Spherical Ball Bearing model 22322 is an essential component for applications demanding high reliability under misalignment and vibration conditions. Its robust design, combined with its capacity to handle misalignment up to 3 degrees and vibration levels from Z1V1 to Z3V3, makes it indispensable in sectors like manufacturing, agriculture, and heavy machinery. Whether used in conveyor systems, electric motors, or pumps, this bearing unit offers enhanced performance, durability, and ease of maintenance.

Customization:

Our Self-aligning Ball Bearing products offer comprehensive customization services to meet your specific requirements. With an outside diameter range of 19 - 170mm and an external diameter of 32mm, our Self-adjusting Ball Bearing solutions are designed for optimal performance and durability. The model 22322 is available with cage materials including Pressed Steel, Brass, and Polyamide, allowing you to select the best option for your application. Whether you need a Self-aligning Spherical Ball Bearing or a Self-aligning Bearing Unit, our expert team can tailor the design and materials to ensure superior alignment and smooth operation in your machinery.

Support and Services:

Our Self-aligning Ball Bearings are engineered to provide superior performance and reliability in a variety of demanding applications. To ensure optimal operation and longevity of your bearings, we offer comprehensive technical support and services tailored to your specific needs.

Technical support includes expert guidance on bearing selection, installation, lubrication, and maintenance practices. Our team of specialists is available to assist with troubleshooting, performance optimization, and addressing any technical inquiries related to the self-aligning ball bearings.

We also provide detailed product documentation, including installation manuals, maintenance guidelines, and performance specifications to help you maximize the efficiency and service life of your bearings.

In addition, we offer customized solutions such as special designs, materials, and coatings to meet unique application requirements. Our engineering support ensures that each bearing is suited to your operational conditions for enhanced durability and performance.

Regular maintenance services, including inspection, cleaning, and re-lubrication recommendations, are available to keep your bearings operating smoothly and to prevent unexpected downtime.

By choosing our self-aligning ball bearings and support services, you invest in quality, reliability, and expert assistance that help you achieve superior machinery performance and reduced operational costs.

Packing and Shipping:

Our Self-aligning Ball Bearings are carefully packaged to ensure maximum protection during transit. Each bearing is wrapped in anti-corrosive paper and placed inside a sturdy, cushioned box to prevent any damage from shocks or vibrations.

For bulk orders, bearings are securely packed in durable cartons with appropriate padding materials to maintain stability and avoid movement within the package.

All packages are labeled with handling instructions and product details to facilitate smooth processing and delivery.

Shipping is carried out through reliable carriers, with options for expedited or standard delivery based on customer requirements. We also offer tracking services to keep you informed about the shipment status until it reaches your doorstep.

FAQ:

Q: What is a self-aligning ball bearing?

A: A self-aligning ball bearing is a type of bearing that allows for angular misalignment between the shaft and the housing, providing smooth operation even if the shaft is slightly bent or misaligned.

Q: What materials are used in the construction of self-aligning ball bearings?

A: Self-aligning ball bearings are typically made from high-quality chrome steel for durability and corrosion resistance, with cages made from steel, brass, or polymer materials depending on the application.

Q: What are the common applications for self-aligning ball bearings?

A: These bearings are commonly used in agricultural machinery, electric motors, conveyors, and other equipment where shaft deflection or misalignment is expected during operation.

Q: How do self-aligning ball bearings handle misalignment?

A: The design includes two rows of balls and a common spherical raceway in the outer ring, which allows the inner ring to tilt slightly while maintaining smooth rotation, compensating for shaft misalignment.

Q: What are the typical sizes and load capacities available for self-aligning ball bearings?

A: Self-aligning ball bearings come in a wide range of sizes, from small miniature bearings to large industrial sizes, with load capacities varying accordingly to support both radial and moderate axial loads.
